Weatherfold 150

Brio’s Weatherfold 4s 150 takes exterior bifolds to another level. An architectural hardware system for top hung exterior folding doors with the capacity to handle panels up to 330lbs with precision and ease. Openings as large as 13’1″ high and 64′ 3″ wide can be achieved with 8 equal size panels folding seamlessly in each direction with inward or outward opening functionality. Suitable for aluminium and timber doors with non-mortice hinges in Satin Stainless (SS) and PVD Black (PR).



Top hung folding door hardware system for aluminum and timber doors, weighing up to 330lbs (150kg).

  • For residential and commercial folding systems where weatherproofing of the opening is required
  • Large openings of 13ft 1in high and 3ft 11in wide can be achieved with 8 equal sized leaves folding seamlessly in each direction with inward and outward opening functionality
  • Supplied with precision stainless steel bearings and 316 marine stainless steel cast hangers for extra corrosion resistance
  • For lighter doors use Weatherfold 100.

  • Max Panel Weight: 330lbs (150kg)
  • Max Panel Width: 3ft 11in (1200mm)
  • Max Panel Height: 13ft 1in (4000mm)
  • Min Panel Thickness: 1 3/4 – 2 3/4in (44-68mm)
  • Max Number of Panels: 8 each way
